GENERATOR |
Phase |
Single
|
|
Rated Voltage |
230V |
|
|
Frequency |
50Hz |
|
|
Rated Power |
1800W |
|
|
Max Power |
2000W |
|
|
Factor |
1.0 |
|
|
Rated Current |
120A |
|
|
WELDING |
Current Output |
60-120A |
|
Rated Voltage |
22-28V |
|
|
Floating Voltage |
DC 70V |
|
|
Welding Rod Dia |
2.0-3.2mm |
|
|
ENGINE |
Bord*stroke (mm) |
70*54 |
|
Displacement (ML) |
212 |
|
|
Max power (hp/rpm) |
7.5/3600 |
|
|
Staring Method |
Recoil/E-Start |
|
|
Fuel tank capacity (L) |
3.6 |
| Engine type | Single cylinder, 4-stroke, top valve |
| Bord*stroke (mm) | 70*54 |
| Displacement (ML) | 212 |
| Max power (hp/rpm) | 7.5/3600 |
| Max. output (N.m/rpm) | 15/2500 |
| Fuel designation | Unleaded gasoline |
| Fuel consumption (g/Kw.h) | <395 |
| Fuel tank capacity (L) | 3.6 |
| Dimension L*W*H (mm) | 570*450*480 |
| N.W (KG) | 34 |
| Product Keywords | welder,25kw gasoline welder_generator,gasoline generator and welding machine |
|
GENERATOR |
Phase |
Single
|
|
Rated Voltage |
230V |
|
|
Frequency |
50Hz |
|
|
Rated Power |
1800W |
|
|
Max Power |
2000W |
|
|
Factor |
1.0 |
|
|
Rated Current |
120A |
|
|
WELDING |
Current Output |
60-120A |
|
Rated Voltage |
22-28V |
|
|
Floating Voltage |
DC 70V |
|
|
Welding Rod Dia |
2.0-3.2mm |
|
|
ENGINE |
Bord*stroke (mm) |
70*54 |
|
Displacement (ML) |
212 |
|
|
Max power (hp/rpm) |
7.5/3600 |
|
|
Staring Method |
Recoil/E-Start |
|
|
Fuel tank capacity (L) |
3.6 |
